MEDER electronic
CONTACT DATA
MK16 Series
Reed Sensors for
SMD Mounting
All Data at 20° C
Contact Form →
Form A
Contact Ratings
Conditions
Min.
Typ.
Max. Units
Switching Power
Switching Voltage
Switching Current
Carry Current
Static Contact Resistance
Dynamic Contact Resistance
Insulation Resistance across Contacts
Breakdown Voltage across Contact
Operate Time incl. Bounce
Release Time
Capacitance
Any DC combination of V & A not to
exceed their individual max.‘s
DC or peak AC
DC or peak AC
DC or peak AC
w/ 0.5 V & 10 mA
Measured w/ 0.5 V & 50 mA ,
1.5 ms after closure
100 volts applied
Voltage applied for 60 sec. min.
Measured w/ 100 % overdrive
Measured w/ no coil suppression
at 10 kHz cross contact
10 12
230
0.2
10
200
0.5
0.5
150
200
0.6
0.1
W
V
A
A
mΩ
mΩ
Ω
VDC
ms
ms
pF
Contact Operation *
Must Operate Condition
Must Release Condition
Steady state field
Steady state field
10
4
30
18
AT
AT
Environmental Data
Shock Resistance
Vibration Resistance
1/2 sinus wave duration 11 ms
From 10 - 2000 Hz
30
20
g
g
Ambient Temperature
Stock Temperature
Soldering Temperature
10°C/ minute max. allowable
10°C/ minute max. allowable
5 sec. dwell
-40
-50
130
130
360
o
o
o
C
C
C
Please note: The indicated electrical data are maximum values and can vary downwards when using a more
sensitive switch.
* These ranges refer to the uncut / unmodified Reed Switches described in our Reed Switch section. Consult factory if
more detail is required.
www.meder.com
259
